OpenScape Alarm Response Pro V5 (OScAR-Pro)
Enterprise alarm server for critical alarm management, mass notification and crisis communication. Scales to 20,000 subscribers, 2,000 call profiles and 500 parallel telephony/messaging channels; connects to PBXs via ISDN or VoIP trunking (also encrypted). Hardware (OScAR 200/300/400) or virtual (VMware) deployment; cluster of two load-sharing servers plus hot-standby redundancy. Mitel OEM product based on tetronik DAKS.
Specifications
- Tip / Type
- Alarm Response, Mass Notification + kriz iletişimi sunucusu / crisis communication server
- Versiyon / Version
- V5 (OScAR-Pro)
- Abone kapasitesi / Subscribers
- 20.000 (her abonede 4 iletişim hedefi / 4 destinations each)
- Çağrı profili / Call profiles
- 2.000 (profil başına 2 arama fazı × 20 hedef / 2 call phases × 20 destinations)
- Kanal / Channels
- 5–500 paralel telefoni/mesajlaşma kanalı / parallel channels
- Donanım platformları / Hardware platforms
- OScAR 200 (5–30 kanal) · OScAR 300 (5–480) · OScAR 400 (5–500) · sanal/virtual (VMware)
- Sinyalleşme / Signalling
- SIP / SIP-Q, ISDN trunk (şifreli VoIP desteği / encrypted VoIP)
- Harici entegrasyon / External integration
- ESPA-X (LAN üzerinden 5 adede kadar), seri portlar, I/O kontak modülleri (IOG/IOM), SNMP, e-posta
- Yedeklilik / Redundancy
- 2 aktif (load-sharing) + 2 hot-standby sunuculu küme / cluster
- Güvenilirlik / Reliability
- MTBF > 400.000 saat; dönen parça yok (disk/fan'sız); OScAR 400: Secure Boot + imzalı OS + AES256 SSD şifreleme
- Çok kiracılı / Multi-client
- 100 kullanıcı grubuna kadar / up to 100 user groups
Key features
- Three platforms: OScAR-Pro 200 (1U, 30 channels), 300AV/AI (3U, 480 channels), 400 (2U, 500 channels — AES-256 SSD, passive cooling, e-paper display).
- Connectivity: VoIP or ISDN trunks; SIP, SIP-Q, QSIG, CorNet-NQ, DSS1, NI2, MLPP protocols.
- Communication channel concept — concurrent calls / messaging dialogs; 200 max 30, 300 max 480 parallel.
- Conferencing and broadcast: parallel call to as many people as channels (60 channels ≈ 200 people alerted in 3–4 minutes).
- Base license (B130): 1 telephony + 1 text trunk, 5 channels, Broadcasting/Alerting-Pro app, ESPA/TAP/IP-Socket host interface, 20 operators + 20 admins.
- Expansion: B138 +5 channels, B139 +50 channels (300/400), Personal Security (B171) lone-worker, Conferencing-Pro (B148), Call Profiles-Pro (B150), Intelligent Calling (B151).
- DECT/IP handset integration: receives handset location via OScAR Cordless IP V2 system (visited + neighborhood base, signal strength).
- DGUV BGR139 (German lone-worker safety) — proven compliance with M3 Plus + OScAR.
- Expansion boards (300 series): PRA (4× E1/S2M/T1 = 120 ISDN channels), SIO (4× RS232/RS422/RS485 fire/BMS integration), DIO (16 digital inputs + 8 outputs + fault contact, cable included).
- Hot-Standby: secondary OScAR for automatic failover; HOT-Standby license (B188) priced at 50% of main licenses.
- Redundant PSU (AC/AC, DC/DC or mixed), Active/Hot-Standby LAN switching.
- Web-based operator + admin UI, OCO (Customized Operator B167) for graphical/map-based control.
- Modules: Broadcasting/Alerting · Conferencing · Call Profiles · Positioning (DPS) · DCO Designer (customized operator UIs) · Personal Security (DGUV 112-139 lone-worker protection) · On-Call Management · Info Telephone · Intelligent Calling · OScAR Mobile Client (iOS/Android) · OScAR Desktop Client · Notifier-Pro · Gateway · Mail2Phone · IoT (Node-RED) · MS Teams integration · OScAR-Pro Satellite (remote site I/O + ESPA)
Typical applications
Hospital staff safety — M3 Plus DECT + OScAR for psychiatry / lone-worker pull-cord, Man Down, No Movement alarms.
Manufacturing fire management — SIO connects fire panel + DECT broadcast evacuates 200 workers.
Government facility emergency escalation — DIO dry-contact alarm chain + OCO graphical map control.
Hotel emergency evacuation — mass broadcast to 500 guest-room phones, M3 Ex Plus for security.
Petrochemical / refinery hazardous zone — M3 Ex Plus + OScAR + ATEX for lone workers.
Government command center — OCO Customized Operator with large-screen map + incident prioritization.
